H-Beams, also known as Wide Flange Beams or Universal Beams, are heavy-duty structural components fundamental to the construction of large-scale buildings, bridges, and industrial facilities. Distinguished by their wide flanges and substantial web, H-beams provide exceptional resistance to axial compression and bending, making them ideal for column applications and heavy load-bearing structures. We offer a comprehensive range of European H-Beam profiles: HEA, HEB, and HEM series.
Understanding Our H-Beam Profiles
1. HEA Series (Light Wide Flange Beams)
The HEA beam is the lighter variant within the H-beam family, featuring thinner flanges and web compared to HEB and HEM profiles of the same nominal depth. It is an excellent choice for structural applications where a balance between strength and weight reduction is desired.
- Key Features: Lighter weight, efficient for moderate loads.
- Typical Applications: Residential and light commercial buildings, roof trusses, and secondary support structures.
2. HEB Series (Standard Wide Flange Beams)
The HEB beam represents the standard European H-profile, offering a robust and balanced design with medium flange and web thicknesses. Its widespread use makes it a versatile choice for a vast array of construction projects that demand reliable strength and durability.
- Key Features: Balanced strength and weight, highly versatile.
- Typical Applications: Industrial warehouses, bridge construction, heavy-duty floor beams, and primary building columns.
3. HEM Series (Heavy Wide Flange Beams)
The HEM beam is the heaviest and most robust H-profile, characterized by significantly thicker flanges and web. Engineered for extreme loads and high-stress environments, HEM beams provide unparalleled strength and rigidity for critical structural elements.
- Key Features: Maximum load-bearing capacity, extreme rigidity.
- Typical Applications: High-rise buildings, large span bridges, heavy machinery foundations, and offshore structures.
Key Characteristics & Benefits
- Exceptional Axial & Bending Strength: H-Beams excel in resisting both compressive forces (as columns) and bending moments (as beams), offering superior structural integrity.
- High Stability & Rigidity: The wide flanges provide enhanced stability, making them suitable for structures requiring high resistance to buckling.
- Diverse Load Capabilities: The availability of HEA, HEB, and HEM series allows for precise selection based on specific load requirements, optimizing material usage.
- International Standards: Produced in accordance with European standards (e.g., EN 10025), ensuring consistent quality and performance.
Technical Overview
Our H-Beams are available in a full spectrum of sizes, typically ranging from HE 100 to HE 1000 for all three series (HEA, HEB, HEM). They are supplied in various structural steel grades, including S235JR, S275JR, and S355J2, to meet the specific strength and ductility demands of any engineering project.
| Series | Description | Flange & Web Thickness | Primary Use |
| HEA | Light Wide Flange | Thinner | Moderate loads, weight-sensitive |
| HEB | Standard Wide Flange | Medium | General construction, high loads |
| HEM | Heavy Wide Flange | Thicker | Extreme loads, critical structures |
